This is the most complete version of Laboratory Filterpress Station designed and builted by Autemi.
With this model customer can test every kind of sludge or liquid to filter, because the micro-filterpress is equipped with all the most important auxiliary and devices we can find in a complete industrial filterpress.
Provided with high pressure feeding pump (up to 15 bar), sludge tank with electric mixer, water tank for water flushing of the piping and pressure multiplier to provide air pressure up to 16 bar for membrane squeezing.
Electric panel allows you also to change the feeding pump flow rate due to VFD installed in order to test which is the best filtration velocity to mantain during the test.
A pressure switch installed over the compensation bag turns ON/OFF automatically the feeding pump.
Available in 4 different versions:
BASIC, STANDARD, PLUS and TOP
Each version of LAB200-CEFS pilot filterpress, can mount from 3 to 15 filtering plates.
Recessed plates or membrane squeezing plates system depends on the choosen version: only PLUS and TOP version can install membrane squeezing plates
Materials available: Polypropylene, AISI 304, AISI 316.
Filtering volume depends on the selected materials
Click on the icon to be redirected to a specific page where you will be able to understand the filtering volumes, the filtering areas and how to compose your filter pack to obtain the desired performances.
The LAB200 series of pilot filterpress unit can be customized in terms of n° of installed plates and materials.
Fill the form with all the required information and we will contact you for a tailor made solution for your application
